Introducing Uni Rack, a versatile industrial racking solution provided by West Coast Suppliers. This system, also known as Adjustable Pallet Racking or selective pallet racking, offers exceptional cost-effectiveness and efficiency for storing and retrieving pallets. With easy direct access to each pallet in storage and a wide range of sizes available, Uni Rack provides remarkable flexibility.
Uni-Rack Racking
Designed to accommodate various storage needs, Uni Rack can handle light to extra heavy-duty storage requirements, supporting pallets, timber decks, steel decks, or steel stillages. Compared to other high-density storage systems, this adjustable pallet racking solution offers a remarkably low cost per pallet stored.
Widely recognized and used in South Africa, adjustable pallet racking is favored for its versatility and cost-efficiency. These systems allow for vertical storage up to 11 meters, maximizing the utilization of available space. Moreover, they provide the flexibility to implement either batch FIFO (First in, first out) or LIFO (Last in, first out) operation, catering to different inventory management needs.
Uni Rack delivers 100% selectivity in high rise racking, making it suitable for a wide range of warehouses and distribution centers. Notably, its easily relocatable and adjustable features add to its remarkable flexibility, allowing for efficient adaptation to evolving storage requirements.
Box Beam Thicknesses
75mm Open / 75mm Box / 95mm Box / 115mm Box / 135mm Box /155mm Box
Components
Uni Rack End Frames (7900kg)/Uni Rack Beams/Uni Rack Braces/Bolt-on Base Feet 140mm x 90mm/Splice Kit for Uprights/ Frame Post Protectors/Wooden Decks
Colours
- Uni Rack End Frames – Mint Green
- Uni-Light Open Beams – Orange
- Bolt-On Feet – Pre Galv
Application
Often used for ambient and cold storage of consumer goods, paper, timber, chemicals, still ages and heavy components and parts. Allows easy, direct access to items with 100% accessibility and can store loads of varying sizes, shapes and weight on the same rack. Convenient for organisations and businesses which carry a large array of stock.
Features:
- Frame Upright
- Bracing Channel
- Spacer Tube
- HTR Bolt & Nut
- Base Foot
- Floor Anchor
- Splice Plate
- Adjustable Beam
- Beam safety Lock
- Row Spacer
- Frame Post Protector
- Slatted Timber Deck
- Mesh Deck
- Steel Deck
- Deck Support
- Slave Pallet Support
- Skid Channel Support
- Coil/Drum Chocks
| Height (H) | Depth (D) | Length (L) |
|---|---|---|
| 1524mm | 610mm | 914mm, 3962mm |
| 1829mm | 762mm | 1219mm, 4267mm |
| 2134mm | 838mm | 1524mm |
| 2438mm | 914mm | 1829mm |
| 2743mm | 1067mm | 2134mm |
| 3048mm | 1219mm | 2438mm |
| 3353mm | — | 2743mm |
| 3658mm | — | 3048mm |
| 3962mm | — | 3353mm |
| 4267mm | — | 3658mm |
